NOVA-945GSE-N270 - EOL

Produkt wycofany z produkcji. EOL

Features

• Intel Atom Processor N270 1.6 GHz for fanless support
• DDR2 400/533 SO-DIMM memory support up to 2 GB
• Support dual PCIe mini card/ PCI slot for expansion
• Dual LVDS support dual display output
• CF socket for storage expansion
• TPM support
• IEI One Key Recovery solution allows you to create rapid OS backup and recovery

Specifications

• CPU: Intel Atom N270 1.6 GHz with a 533 MHz FSB
• System Chipset: Intel 945GSE+ICH7M
• BIOS: AMI BIOS
• Memory: One 200-pin 400/533 DDR2 SDRAM SO-DIMM supported (system max. 2 GB)
• Ethernet: Dual Realtek PCIe RTL8111CP GbE LAN
• Graphic: On Intel Graphics Media Accelerator 950
• I/O Interface:
  3 x RS-232
  1 x RS-232/422/485
  6 x USB 2.0
  2 x SATA with 5V output
  1 x LPT
  1 x IDE
  1 x 6-pin header for KB/MS
• Expansion:
  1 x PC/104+ (ISA+PCI bus)
  2 x PCIe mini card
  1 x PCI
• Digital I/O: 8-bit digital I/O (4-bit input, 4-bit output)
• Infrared Interface: 1x 5-pin Infrared Interface by pin header
• Super IO: ITE8718F
• Display Output:
  Analog CRT Support for CRT Hot plug
  Support HDTV by component interface
  18 bit dual-channel LVDS by Intel 945GSE
• Audio: AC'97 ALC655 codec
• SSD: CF Type II
• Watchdog Timer: Software programmable support 1~255 sec. system reset
• TPM: 1x 20-pin header
• Power Supply: 5 V only, 12 V for LCD/System FAN, AT/ATX
• Power Consumption: 5 V@3.49 A
  (Intel Atom N270 with 512 MB DDR2)
• Temperature: Operation: 0 ~ +60° C (32 ~ 140° F)
• Humidity: Operation: 5% ~ 95%, non-condensing
• Dimensions: 203 x 146 mm
• Weight: GW:1000 g, NW:400 g

Ordering Information

• NOVA-945GSE-N270-R20 - 5.25" SBC, Intel Atom N270 1.6 GHz, 18 bits LVDS/ VGA/HDTV, Dual PCIe Mini, Dual PCIe GbE, USB 2.0, SATA, RoHS

Optional Accessories

• HDTVCABLESET-01 - HDTV cable set with S-Video, composite and component Interfaces

• 32200-000009-RS - 44-pin 2.5" IDE cable

• 32102-000100-200-RS - SATA power cable

• 32200-015100-RS - LPT cable

• WMPCIE-V01-R30 - 802.11b+g PCIe mini card wireless LAN module

• WMUSB-V01-R20 - 802.11b+g USB embedded module

• 32200-833600-RS - RS-422/485 cable
