HPERC-IBRMH-B01NS7

Extreme Rugged MIL-STD chłodzony konwekcyjnie system komputerowy z procesorem 3 generacji dual-core Intel Core i7-3517UE 1.7 GHz, 8 GB ECC DDR3L RAM, 2x 64 GB SLC SSD, VGA, 4x GbE, 7x RS-232/422, 6x USB 2.0, 2x SATA-3 z RAID i HD-audio (-40 ~ +75°C); zasilanie 9 ~36 Vdc; OS Windows Standard 7 (64-bit)

Features

• SWaP efficient sealed SFF system
• VITA 75.21 coldplate mounting
• Intel Core i7 dual-core Processor
• Soldered DDR3L-1333, up to 16 GB RAM
• Quad Gigabit Ethernet
• Ultra-fast Solid-State-RAID
• Available GPGPU on 16-lane 3rd Generation PCI Express
• Triple DisplayPort/HDMI/DVI
• Simple user expansion and configuration
• Extreme Rugged operating temperature: -40 ~ +75°C

Ordering Information

• HPERC-IBRMH-B01NS7 - High Performance Extreme Rugged MIL-STD Finned-convection System with Gen3 dual-core Intel Core i7-3517UE 1.7 GHz CPU, 8 GB ECC DDR3L RAM, 2x 64 GB SLC SSD and VGA, 4x GbE, 7x RS-232/422, 6x USB 2.0, 2x SATA-3 with RAID and HD-audio interface (-40 ~ +75°C); 9 ~ 36 Vdc power; OS Windows Standard 7 (64-bit)

Optional Accessories

• HPERC-X-01 - HPERC breakout cable kit including all IO and AC adapter


• DDR3L-HPERC - HPERC 16 GB RAM option


• CC-DDR3-HPERC - Comformal Coating option for HPERC 16 GB RAM option


• CC-HPERC-IBR - Conformal Coating option for HPERC-IBR


• 1553-HPERC - PCI/104 Express MIL-STD-1553 option


• 429-HPERC - PCI/104 Express ARINC-429 option


• E6760-HPERC - AMD E6760 600 MHz GPGPU with 800 MHz 128-bit 1 GB GDDR5 Memory
