2I385C-E3815/2GB

Komputer jednopłytkowy 2.5" z procesorem single-core Intel Atom E3815 1.46 GHz, 2 GB DDR3L SDRAM, VGA/LVDS, 2x GbE, 1x RS-232/422/485, 3x RS-232/485, 4x USB 2.0, 1x SATA i HD-audio (-20 ~ +70°C); zasilanie +12 Vdc

Features

• Embedded Intel Bay Trail-I E3815 CPU / chipset
• On Board 2 G DDR3L, VGA, HD Audio, 4x COM
• 2x Intel GbE LAN, 4x USB 2.0
• 2x Mini PCIe

Specifications

• CPU Type: Bay Trail-I E3815 1.46 GHz (Single core processor)
• MB Chipset: Intel Bay Trail-I E3815 chipset
• BIOS: Insyde UEFI BIOS
• Graphics:
  Intel's 7th generation (Gen 7) graphics and media encode/decode engine,
  Supports DX*11, OpenGL 3.0 (OGL 3.0), OpenCL 1.2 (OCL 1.2), OpenGLES 2.0
• System Memory: On Board 2 G DDR3L 1066 MHz
• SSD Storage:
  mSATA: Yes
  On Board SSD: N/A
• VGA: Yes
• LVDS: Dual channel 24/48 bits
• Touch Screen: USB interface Touch Screen controller
• Ethernet: 2x Intel GbE
• Audio: High Definition Audio Specification, Support Line-out/Mic-in
• Mini-PCIe:
  Slot 1: (Full Size) PCIe / USB / mSATA
  Slot 2: (Half Size) USB / mSATA
• SIM Card Holder: -
• SATA: 1 (share with Full size mSATA)
• USB: 4x USB 2.0 (2 x external + 2 x internal)
• Serial IO:
  1 x RS232 ( external) optional to RS422/485 ;
  3 x RS232 ( internal) optional to RS485
• GPIO: 4x DI / 4x DO (Internal)
• WDT: Hardware Watch Dog Timer, 0 ~ 255 sec programmable
• PS2 KB/MS: N/A
• Power Input: On board DC IN +12 V; +9~+36 V Optional
• Expansion: GPS, IEEE1394, 3G/4G, Bluetooth, WI-FI, I/O, Video Card
• Dimension: 102 x 73 mm (2.5 inch)
• Operation Temperature: -20 ~ +70°C
• Operation Humidity: 5 ~ 95%, non-condensing
• Chassis:
  Box PC: TWIN
  Panel PC: 7", 10.1", 13.3" (16:9)
  8.4", 10.4", 12.1", 15", 17" (4:3)

Ordering Information

• 2I385C-E3815/2GB - 2.5" SBC with single-core Intel Atom E3815 1.46 GHz CPU, 2 GB DDR3L SDRAM and VGA/LVDS, 2x GbE, 1x RS-232/422/485, 3x RS-232/485, 4x USB 2.0, 1x SATA and HD-audio interface (-20 ~ +70°C); +12 Vdc power
