IOVU-572M-CE6/ (End of Life)

Bezwentylatorowy komputer panelowy 5,7" 640x480 400 cd/m2 z procesorem XScale PXA310 624 MHz, 256 MB RAM, rezystancyjnym ekranem dotykowym single-touch, 2x LAN, 1x RS-232/422/485, 2x USB 1.1, 802.11b/g Wi-Fi i audio; system Windows CE 6.0

Features

• 5.7” TFT VGA LCD with resistive touch screen
• Marvell XScale PXA310 624MHz processor and 256 MB DDR2
• Built-in 802.11b/g wireless LAN
• Built-in 1.5W speakers
• IP 64 compliant front panel
• Fanless design for rigorous environments
• Preinstalled Windows CE6.0 operating system
• Windows CE6.0 SDK for user application software development

Specifications

• System


• CPU: XScale PXA310 624 MHz
• Operating System: Win CE 5.0
• Bootloader Storage 128 MB
• RAM: 256 MB DDR2
• Program Storage Area:Bootloader Storage


• Display


• LCD Size: 5.7”
• LCD Color: 262 K
• Display Resolution: VGA
• LCD Brightness (cd/m2): 400
• Dot Pitch (mm):0.06(H) x 0.18(V)
• Viewing Angle (H-V): 140 / 100
• Backlight MTBF: 50000
• Touch Screen: Resistor Type
• Multimedia Support: MPEG 1


• I/O and Communication


• I/O Interface:
  1 x RS-232/422/485 (software controllable)
  2 x 10/100Mbps LAN
  2 x USB 1.1 host
  1 x SD card slot
  1 x Reset button
  1 x AT mode power switch
  1 x 2-pin terminal block DC input
• Audio: 2 x 1.5 W speaker
• Wireless LAN: 802.11 b/g


• Dimension


• Construction Material: ABS + PC Plastic
• Net Weight (kg): 0.7
• Front Panel Color: Black
• Dimensions (W x H x D): 180 x 135 x 46 mm


• Enviromental


• Operating Temperature: -10 ~ +60°C
• Humidity: 5 ~ 90% RH
• Front Panel Protection: IP64 compliant


• Power


• Power Mode: AT
• Power Requirement: 12 ~ 36 Vdc
• Power Consumption: 14 W

Ordering Information

• IOVU-572M-CE6/-R11 - 5.7” RISC Fanless panel PC, LCD, Marvell PXA310 624MHZ, built-in Wi-Fi, WIN CE6.0, RoHS

Optional Accessories

• AFLPK-12 - Panel mounting kit


• AFLWK-12 - VESA 75 wall mounting kit


• ARM-11-RS - LCD monitor/PPC arm kit, loading capacity from 3kg~7kg


• STAND-A08-RS - LCD monitor/PPC stand kit for VESA 75 and supports up to 5 Kg


• VSTAND-A07 - LCD monitor/PPC stand V type for VESA 75, 0~90 degree adjustable hinge and support up to 2.5 Kg


• AFLP-12BMSR-U - USB magnetic card reader


• AFLP-BRW01-U - USB barcode reader (white)


• AFLP-BRB01-U - USB barcode reader (black)


• AFLP-CDB01 - VFD customer display (green) 5 x 7 dot matrix (black)


• AFLP-CDW01 - VFD customer display (green) 5 x 7 dot matrix (white)


• 63000-FSP060DBAB1555-RS - 12 V/5 A DC 60 W power adapter with bare wire, 90~264 Vac input
