Features:
- Onboard Intel® Celeron®/Atom™ SoC J1900/E3845 BGA Processor
- One 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1066/ 1333 SDRAM
- Dual View, 2-CH LVDS, CRT, HDMI
- 2 x Gigabit Ethernet
- HD Audio/ Fanless Operation
- 1 CF, 1 SATA II, 1 Mini-PCIe, 1 USB 3.0, 5 USB 2.0, 4 COM, 8-bit GPIO
System | |
Processor | Intel® Atom™ E3845 4-Core 1.91GHz processor Intel® Celeron® J1900 4-Core 2.0GHz processor |
System Memory | 1 x 204-Pin DDR3L 1066MHz SO-DIMMup to 8 GB or 1 x 204-Pin DDR3L 1333MHz SO-DIMMup to 8 GB Processor E3845 & J1900 only support 1333MHz |
I/O Chip | EC ITE IT8528E |
BIOS | AMI uEFI BIOS, 64Mbit SPI Flash ROM |
Watchdog Timer | H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step |
H/W Status Monitor | Monitoring SYSTEM Temperature, Voltage and FAN Status with Auto Throttling Control |
Expansion | |
Expansion | 1 x Mini PCIe Supports mSATA |
Storage | |
Storage | 1 x CompactFlash Type I/II Socket |
Touch Screen | |
Built-in Touch controller(optional) | Chipset:PenMount 6000 Touch Screen Interface:With 5-pin 2.0mm Box Header (Can be Selected to Support 4/ 5Wire Touch Screen) |
I/O | |
USB | 5 x USB 2.0 1 x USB 3.0 |
SATA | 1 x SATA II |
COM Port | 1 x RS-232/422/485 3 x RS-232 |
DIO | 1 x 8bit GPIO |
MIO | 1 x LPC 1 x PS2/ KB & MS |
Display | |
Chipset | Intel® Valleyview SoC integrated Graphics Supports dual display |
Resolution | VGA:Max. resolution 2560x1080@ 60Hz HDMI:Max. resolution 1920x1200@ 60Hz LVDS:Max. resolution 1920x1080@ 60Hz CRT + LVDS, HDMI + LVDS, CRT + HDMI Dual-channel 18/ 24-bit LVDS |
Audio | |
Chipset | Realtek ALC892 Support 5.1-CH |
Audio Interface | Mic-In, Line-In and Line-Out |
Ethernet | |
Chipset | 2 x Intel® I211AT |
Ethernet Interface | 10/100/1000 Base-Tx GbE compatible |
LAN Port | 2 x RJ-45 |
Mechanical & Environmental | |
Power Requirement | +12V ~ +26V |
ACPI | Single Power ATX Support S0, S3, S4, S5 ACPI 3.0 Compliant |
Power Type | AT/ATX |
Operating Temp | 0°C ~ 60°C (32°F ~ 140°F) -40°C ~ 85°C (-40°F ~ 185°F) (Optional for Wide Temperature Model) |
Storage Temp | -40°C ~ 75°C (-40°F ~ 167°F) |
Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
Dimension (L x W) | 5.7" x 4" (146mm x 101mm) |
Weight | 0.44lbs (0.2kg) |
Certifications | |
Certification Information | CE FCC Class B |
Software Support | |
OS Information | Win 10 Win 8 Win 7 Linux |
