Features
- Powered by high performance Intel Core i3-350M 2.26 GHz CPU with Intel HM55 chipset
- 1066 MHz DDR3 system memory up to 4 GB
- HDMI port delivers high image quality on the second display
- IEI One Key Recovery solution allows you to create rapid OS backup and recovery (over 4 GB storage capacity is suggested)
Specifications
- LCD Size: 19”
- Max Resolution: 1280 x 1024
- Brightness (cd/m2): 450
- Contrast Ratio: 1000 : 1
- LCD Color: 16.7M
- Pixel Pitch (mm): 0.294 (H) x 0.294 (V)
- Viewing Angle (H-V): 178º / 178º
- Backlight MTBF: 50000 hrs
- SBC Model: AFLMB2-HM55-R10
- CPU: Socket G (PGA989A) Intel Core i3-350M 2.26 GHz CPU
- Chipset: Intel HM55
- RAM: Two 204-pin 800/1066 MHz DDR3 dual-channel SO-DIMMs supported (system max. 8 GB)
- I/O Ports:
1 x RS-232 COM Port
1 x RS-232/422/485 COM Port
2 x RJ-45 for Giga LAN
4 x USB 2.0
1 x Power Switch
1 x Reset Button
1 x Audio Port (Line-out)
1 x VGA
1 x Power Jack
1 x HDMI Port - SSD: SATA SSD
- Watchdog Timer: Software programmable supports 1~255 sec. system reset
- Audio: AMP 3 W + 3 W (internal speakers)
- Wireless Connection: 1 x Wireless LAN 802.11 b/g/n Module (internal PCIe Mini card interface)
- Drive Bay:
1 x 2.5” SATA HDD bay - Construction Front Panel: ABS + PC Plastic front frame
- Membrane Keypad: OSD Keypad below the Front Panel (5 keys)
- LED Function: 1 x Power on/off LED on front panel
- Mounting: Panel, Wall, Stand and Arm VESA 100 x 100 mm
- Front Panel Color: Sliver (877U) & Gray (ABSA2037)
- Dimensions (WxHxD): 470 x 383 x 72 mm
- Operation Temperature: 0 ~ +50°C
- Storage Temperature: -20 ~ +60°C
- N/G Weight: 6.2 Kg
- IP Level: Front Frame IP64
- Touch Screen: Resistive Type 5-Wire (Touch controller IC is on board)
- Power Adapter:
P/N: 63000-FSP096AHB-RS
96 W Power Adapter
Input: 90 ~ 264 Vac, 50/60 Hz
Output: 12 Vdc - Power Requirement: 12 Vdc
- Power Consumption: 88 W
(Intel T7500, 2 GB memory, 80 G HDD)
Ordering Information
- AFL-19i-HM55i3-35/R/2G-R20 - 19" 450 cd/m² SXGA panel PC with Intel Core i3-350M 2.26 GHz CPU, 2 GB DDR3 RAM, 802.11 b/g/n wireless module, touch screen, R11, RoHS
Optional Accessories
- AFLPK-19B - Panel Mounting Kit
- AFLWK-19 - Wall Mounting Kit
- ARM-11-RS - Arm
- ARM-31-RS - Arm
- STAND-A19 - Stand
- STAND-B19 - Stand
- STAND-210-R11 - Stand
- AFLP-19AMSI-U - Hybrid Card Reader
- AFLP-19AMSR-U - Magnetic Stripe Reader
- AUPS-B10-R10 - DC 12 V input, 12 V output 100 W UPS module with 3800 mAH (VESA 100)
- AUPS-B20-R10 - DC 9 ~ 36 V input, 12 V output 100 W UPS module with 3800 mAH (VESA 100)
- AFL-BT-KIT01-R10 - Bluetooth V2.0+EDR
Optional Operating Systems
- AFLSD-19-HM55-2G-XPE-R10 - OS Win XPE (2 GB SATA SSD)
- AFLSD-17-HM55-4G-WES7E - OS Win 7 Embedded (4 GB SATA SSD)
Parametry techniczne:
End of Life: | Tak |
Jeśli potrzebujesz dodatkowych informacji zadzwoń do nas (22 831 10 42) lub napisz wiadomość.
Gwarancja 24 miesiące - Gwarancja udzielana przez sprzedawcę na okres 24 miesięcy.
Gwarancja standardowa 24 miesiące
