Name: EAC-6000-OOB
Brand: Vecow

Karta katalogowa Pobierz

Features

Small form factor NVIDIA® Jetson Orin™ NX supports up to 100 TOPS AI performance
Advanced NVIDIA Ampere™ architecture with 1024 NVIDIA® CUDA® cores and 32 Tensor cores
2 GigE LAN with 4 PoE+, 3 USB 3.1, 2 COM RS-232/422/485
Supports multiple 5G/4G/LTE/WiFi/BT/GPRS/UMTS conntections
1 CAN Bus supports Flexible Data-rate, 7-bit GPIO
DC 9V to 50V wide range power input, Ignition Power Control
Support 24/7 secure remote monitoring, control, and Out-Of-Band management for disaster recovery empowered by Allxon

Feature Highlights

Advanced AI Productivity

NVIDIA Jetson Orin NX Platform, max 8-core Arm Cortex-A78AE v8.2 64-bit CPU, up to 100 TOPS AI performance with power configurable between 10W and 25W, max 918MHz GPU Frequency
Advanced NVIDIA Ampere architecture GPU with max 1024 NVIDIA CUDA cores and 32 Tensor cores
2x NVIDIA Deep Learning Accelerate Engines
LPDDR5x Memory, up to 16GB
Up to 3X the performance of NVIDIA Jetson AGX Xavier, up to 5X the performance of NVIDIA Jetson Xavier NX

Compact Integration

Powered by the smallest Jetson form factor
Max 6 GigE LAN with 4 IEEE 802.3at PoE+
3 USB 3.1, up to 10Gbps data transfer
Supports GMSL Gen 2/Gen 1 automotive cameras via 4 FAKRA-Z connectors
2 COM RS-232/422/485, 2 External SIM Socket, 7-bit GPIO
CAN Bus supports Flexible Data-rate (CAN FD)
Max 8K resolution, Video Encode, Video Decode
Multiple Compact M.2 Socket : 2 M.2 Key B, 1 M.2 Key E, 1 M.2 Key M
Device Management : Remote Monitoring, Disaster Recovery, Version Control

Mobile Availability

Compact Size, Rugged Designs
With power configurable between 10W and 15W
Multiple 5G/4G/LTE/WiFi/BT/GPS connection supports seamless wireless communication
CAN Bus and FAKRA-Z for Autoware applications
Software Ignition Control optimized for in-vehicle operation
Optional Out-Of-Band management for disaster recovery

Trusted Reliability

Fanless -25°C to 70°C operation
DC 9V to 50V wide range power input
Max 25W Power Productivity
Software Ignition Power Control
Optional Rugged X-coded PoE+ LAN
EN50155 and EN50121-3-2 compliant
Military-grade MIL-STD-810G Compliant

Parametry techniczne:

System
System - CPU:	EAC-6000-OOB-R16 : 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU , EAC-6000-OOB-R08 : 6-core Arm® Cortex®-A78AE v8.2 64-bit CPU
System - GPU:	1024-core NVIDIA Ampere™ architecture GPU with 32 Tensor cores
System - DL Accelerator:	EAC-6000-OOB-R16 : 2x NVDLA Engines , EAC-6000-OOB-R08 : 1x NVDLA Engine
System - Memory:	EAC-6000-OOB-R16 : 1 16GB LPDDR5 DRAM , EAC-6000-OOB-R08 : 1 8GB LPDDR5 DRAM
System - Software Support:	Linux , NVIDIA JetPack SDK
I/O Interface
I/O Interface - USB:	1 USB 3.1 Gen 2 , 2 USB 3.1
I/O Interface - Serial:	2 COM RS-232/422/485
I/O Interface - CAN Bus:	1 CAN Bus supports CAN FD
I/O Interface - GPIO:	7-bit GPIO
I/O Interface - Micro USB:	1 Micro USB Console Port , 1 Micro USB Recovery Port
I/O Interface - Button:	1 Power Button , 1 Force Recovery Button , 1 Reset Button
I/O Interface - LED:	Power, SSD
I/O Interface - SIM:	2 SIM Card Socket
I/O Interface - Antenna:	6 Antenna for WiFi/4G/5G/LTE/GPRS/UMTS
Expansion
Expansion - M.2:	2 M.2 Key B Socket (3042/3052, USB3) , 1 M.2 Key E Socket (2230, PCIe/USB)
Graphics
Graphics - Interface:	1 HDMI : Up to 3840 x 2160 @60Hz
Graphics - Video Encode:	HEVC : 1x 4K @60, 3x 4K @30, 6x 1080p @60, 12x 1080p @30 , H.264 : 1x 4K @60, 2x 4K @30, 5x 1080p @60, 11x 1080p @30
Graphics - Video Decode:	HEVC : Up to 1x 8K @30, 2x 4K @60, 4x 4K @30, 9x 1080p @60, 18x 1080p @30 , H.264 : Up to 1x 4K @60, 2x 4K @30, 5x 1080p @60, 11x 1080p @30
Storage
Storage - M.2:	1 M.2 Key M 2280, up to 1TB NVMe SSD pre-installed
Storage - SD:	1 Micro SD (External)
ETHERNET
Ethernet - LAN 1:	10/100/1000 Base-T Ethernet GigE LAN, RJ45 Connector (Optional X-coded M12 Connector)
Ethernet - LAN 2:	10/100/1000 Base-T Ethernet GigE LAN, RJ45 Connector (Optional X-coded M12 Connector)
Power
Power - Power Input:	DC 9V to 50V
Power - Power Interface:	3-pin Terminal Block : V+, V-, Frame Ground
Power - Ignition Control:	16-mode Software Ignition Control
Power - Remote Switch:	3-pin Remote Switch Terminal Block
Out-of-Band Management
Out-of-Band Management - MCU:	Nuvoton NUC980
Out-of-Band Management - Interface:	1 10/100Mb Ethernet LAN, RJ45 Connector , 1 Full-Size Mini PCIe Socket (USB) , 1 Nano SIM
Out-of-Band Management - Remote Management:	Remote Management
Mechaniczny
Mechanical - Dimensions:	193 mm x 132 mm x 80 mm (7.6" x 5.2" x 3.15")
Mechanical - Weight:	1.9 kg (4.19 lb)
Mechanical - Mounting:	Wallmount , DIN Rail (Optional)
Środowisko
Environment - Operating Temperature:	15W TDP Mode : -25°C to 70°C (-13°F to 158°F), with 0.63 m/s air flow , 25W TDP Mode : -25°C to 55°C (-13°F to 131°F), with 0.63 m/s air flow
Environment - Storage Temperature:	-40°C to 85°C (-40°F to 185°F)
Environment - Humidity:	5% to 95% Humidity, non-condensing
Environment - Relative Humidity:	95% @ 70°C
Environment - Shock:	Operating, MIL-STD-810H, Method 516.8, Procedure I
Environment - Vibration:	Operating, MIL-STD-810H, Method 514.8, Procedure I, Category 4
Environment - EMC:	CE, FCC, EN50155, EN50121-3-2
