Features
- PICMG 1.0 and RoHS compliant
- Intel Atom processor N270 at 1.6GHz core speed with a 533MHz FSB and 512KB L2 cache
- Enhanced technology for lower Power Consumption
- Two SATA and CF type I/II for data storage
- IEI One Key Recovery solution allows you to create rapid OS backup and recovery
- CPU: On board Intel Atom N270 processor 1.6 GHz 512 KB L2 cache with a 533 MHz FSB
- System Chipset: Intel 945GSE + ICH7M
- BIOS: AMI BIOS
- System Memory: One 240-pin 533/400 MHz DDR2 SDRAM DIMM supported (system max. 2 GB)
- Ethernet: Dual Realtek 8111CP PCIe GbE controller
- I/O Interface:
2 x RS-232
2 x SATA
1 x IDE
1 x LPT
7 x USB 2.0 (1 on bracket, 6 on board by pin header)
1 x PS/2 connector for KB/MS - Digital I/O: 8 bit digital I/O, 4-bit input/ 4-bit output
- Infrared Interface: 1 x Infrared by pin header
- Super I/O: ITE IT8718F
- Display Interface:
VGA Integrated in Intel 945GSE - Audio:
Support 7.1 channel HD audio or 5.1 channel AC-97 audio by IEI audio kits - SSD: CF type I/II
- Watchdog Timer: Software programmable supports 1 ~255 sec. system reset
- Power Supply: AT/ATX power
- Power Consumption: 5 V@2.55 A, 12 V@0.23 A
(Intel Atom N270 1.6 GHz/533 MHz CPU with 1GB DDR2 533 MHz) - Temperature: Operation: 0 ~ +60°C (32 ~ 140°F)
- Humidity: Operation: 5% ~ 95% non-condensing
- Dimensions: 338 x 122 mm
- Weight: GW: 1.0 kg / NW: 0.25 kg
- WSB-945GSE-N270-R10 - PICMG 1.0 with Intel Atom processor N270 1.6G processor, VGA, Dual PCIe GbE, USB 2.0, SATA
- AC-KIT-888HD-R10 - 7.1 channel HD audio kit with Realtek ALC888 support dual audio streams
- AC-KIT08R-R10 - 5.1 channel AC'97 audio kit with Realtek ALC655
- 32200-000052-RS - ATA 66 flat cable
- 32102-000100-200-RS - SATA power cable
- 19800-000400-100-RS - LPT cable
Parametry techniczne:
| End of Life: | Tak |
Jeśli potrzebujesz dodatkowych informacji zadzwoń do nas (22 831 10 42) lub napisz wiadomość.
