Panel operatorski 2.8" 240x320 160 cd/m2 z rezystancyjnym ekranem dotykowym oraz interfejsem 10/100M LAN (-20 ~ +70°C); zasilanie PoE; maskownica czarna
Features
- Excellent C/P ratio (cost/performance)
- High-resolution color touch screen
- PoE (Power over Ethernet)
- GUI design
- Free HMIWorks development tool
- Suppots C programming language and Ladder Designer
- Supports the custom communication protocol (C language)
- Modbus TCP protocol
- ESD Protection: 4 kV
- Operating temperature: -20 ~ 70°C
Specifications
- CPU Module
- CPU: 32-bit RISC CPU
- Memory Expansion: -
- Real Time Clock (RTC): -
- Buzzer: Yes
- Rotary Switch (0~9): Yes
- Communication Interface
- Serial Port
COM1: -
COM2: - - Ethernet: RJ-45 x 1, 10/100 Base-TX
- MMI (Main Machine Interface)
- LCD: 2.8" TFT (Resolution 240 x 320 , 65535 colors), defective pixels <= 3
- Backlight Life: 20,000 hours
- Brightness: 160 cd/m2
- Touch Panel: Resistive Touch
- Reset Button: Yes
- Electrical
- Powered from Terminal Block: -
- Powered from PoE: IEEE 802.3af, Class1 (48 V)
- Power Consumption: 1.5 W
- Mechanical
- Dimensions (W x L x H): 127 x 92 x 31 mm
- Installation Wall Mount
- Ingress Protection Front Panel: IP40
- Environmental
- Operating Temperature: -20 ~ +70°C
- Storage Temperature: -30 ~ +80°C
- Ambient Relative Humidity: 10 ~ 90% RH, non-condensing
Ordering Information
- TPD-283-M3 CR – 2.8" Touch HMI device with Ethernet, PoE (RoHS); black bezel
Optional Accessories
- 1C016 – 2.4 mm Screw driver
- NS-208PSE CR – Niezarządzalny przełącznik – Industrial PoE (Power over Ethernet) Ethernet Switch (RoHS)
- MDR-60-24 CR – 24 VDC/2.5 A, 60 W Power Supply with DIN-Rail Mounting (RoHS)
