Digital Input
- Channels: 4
- Input Type: Sink, Source, isolated channels with common ground or power
- Off Voltage Level: +1V max.
- On Voltage Level: +4 ~ +30V
- Input Impedance: 3KΩ, 0.5W
- Counters channels: 4
- Max. Counters: 16-bit (65535)
- Max. Input Frequency: 100Hz
- Min. Pulse Width: 5ms
- Photo-Isolation: 3750Vrms
- Channels: 5
- Relay Type: Form "A" relay SPST (N.O.)
- Contact Rating:
AC: 250V @5A
DC: 30V @5A - Operating Time(Max.): 6ms
- Release Time(Min.): 3ms
- Surge Strength: 4,000Vac
- Insulation Resistance: 1000MΩ min. at 500Vdc
- Life Time:
Mechanical: 20 X 10^6 OPS
Electrical: 100 X 10^3 Full Load
- Interface: RS-485
- Format: N, 8, 1
- Baud Rate: 1200 ~ 115200bps
- Protocol: DCON
- 1 LED as Power/ Communication indicator
- 4 LEDs as Digital Input indicators and 5 LEDs as Relay Output indicators
- Input Voltage Range: 10 ~ 30Vdc
- Power Consumption: 1.3W (max.)
- Operating Temperature: -25 ~ +75°C
- Storage Temperature: -40 ~ +85°C
- Humidity: 5 ~ 95% RH, non-condensing
