Analog Output
- Output Channels: 4
- Output Type: 0~20 mA, 4~20 mA, 0~5 V, +/-5 V, 0~10 V, +/-10 V
- Resolution: 14-bit
- Accuracy: +/-0.1% of FSR
- Zero Drift Voltage output: +/-30 uV/°C
- Current output: +/-0.2 uA/°C
- DA Output Response Time: 10 ms per channel
- Span Temperature Coefficient: +/-20 ppm/ °C
- Programmable Output Slope:
0.125 to 2048 mA/ second
0.0625 to 1024 V/ second - Current load resistor:
External +24V power: 1050 Ω - Intra-module Isolation, Field to Logic: 3000 Vdc
- Interface: RS-485
- Format: N, 8, 1
- Baud Rate: 1200 ~ 115200 bps
- 1 LED as Power/ Communication indicator
- Input: +10 ~ +30 Vdc
- Power Consumption: 2.4 W
- Support Modbus and DCON Protocol: Yes
- Operating temperature: -25 ~ +75°C
- Storage temperature: -40 ~ +85°C
- Humidity: 5 ~ 95% RH, non-condensing
