Digital Input
- Channels: 5
- Input Type: Dry Contact (Source)
- Contact Level:
On Voltage Level: Close to GND
Off Voltage Level: Open - Counters:
Max. Count: 16-bit (65535)
Max. Input Frequency: 50 Hz
Min. Pulse Width: 10 ms
- Output Channels: 4
- Range:
0 ~ 5 V, +/- 5 V, 0 ~ 10 V, +/- 10 V,
0 ~ 20 mA, 4 ~ 20 mA - Resolution: 14-bit
- Accuracy: 0.1%
- DA Output Response Time: 10 ms
- Open Wire Detection (for current only): ---
- Channel to Channel Isolation: ---
- Power-on Value: Yes
- Safe Value: Yes
- Interface: RS-485
- Format: (N, 8, 1) (N, 8, 2) (E, 8, 1) (O, 8, 1)
- Baud Rate: 1200 ~ 115200 bps
- Protocols: Modbus RTU, DCON
- Dual Watchdog: Yes, Module (1.6 Seconds), Communication (Programmable)
- System LED Indicator: Yes, 1 LED as Power/Communication Indicator
- Intra-Module Isolation, Field-to-Logic: 3000 Vdc
- ESD (IEC 61000-4-2): +/-4 kV
- EFT (IEC 61000-4-4): +/-4 kV
- RS (IEC 61000-4-3): 5 V/m, 80 MHz ~ 1GHz
- Reverse Polarity Protection: Yes
- Input Range: 10 ~ 30 Vdc
- Consumption: 3.2 W
- Dimensions (W x L x H): 72 x 123 x 35 mm
- Installation: DIN-Rail or Wall Mounting
- Operating Temperature: -25 ~ +75°C
- Storage Temperature: -40 ~ +85°C
- Humidity: 10 ~ 95% RH, Non-condensing
