Digital Input
- Channels: 8
- Type: Sink, Isolated
- ON Voltage Level: +2.4 ~ +5 V
- OFF Voltage Level: +1 V Max.
- Max. Frequency: 1 MHz
- Max. Counts: 32-bits (4,294,967,295)
- Built-in Virtual Battery Backup for Counter Value Yes
- ESD Protection (IEC 61000-4-2):
4 kV Contact for each terminal
8 kV Air for random point - Isolation: 2500 Vdc
- Channels: 8
- Type: TTL, Isolated
- Max. Frequency: 1 Hz~500 KHz
- Duty Cycle: 0.1% ~ 99.9%
- PWM Mode: Burst mode, Continuous mode
- Burst mode counter: 1 ~ 65535 counts
- Trigger Start: Hardware or Software
- ESD Protection (IEC 61000-4-2):
4 kV Contact for each terminal
8 kV Air for random point - Isolation: 2500 Vdc
- Interface: RS-485
- Format: N, 8, 1
- Baud Rate: 1200 ~ 115200 bps
- Input Voltage Range: 10 ~ 30 Vdc
- Power Consumption: 2.4 W (max.)
- Power reverse polarity protection: Yes
- +/- 4 kV ESD , +/- 4 kV EFT and +/- 3 kV Surge Protection: Yes
- Operating Temperature: -25 ~ +75°C
- Storage Temperature: -40 ~ +85°C
- Humidity: 5 ~ 95%, non-condensing
