DAQ-2205

  • Karta 3.3/5 V PCI - 32/64 wejścia analogowe 16-bitowe 500 kS/sek, 2 wyjścia analogowe 12-bitowe 1 MS/sek, 24 wejścia-wyjścia cyfrowe i 2 liczniki 16-bitowe
  • DAQ-2205

Karta 3.3/5 V PCI - 32/64 wejścia analogowe 16-bitowe 500 kS/sek, 2 wyjścia analogowe 12-bitowe 1 MS/sek, 24 wejścia-wyjścia cyfrowe i 2 liczniki 16-bitowe


Features

  • Supports a 32-bit 3.3 V or 5 V PCI bus
  • 64-CH single-ended or 32-CH differential analog inputs
  • Onboard 1 k-sample A/D FIFO
  • Bipolar or unipolar analog input ranges
  • Programmable gains: x1, x2, x4, x8
  • 512-configuration channel gain queue
  • Scatter-gather DMA for both analog inputs and outputs
  • 2-CH 12-bit multiplying analog outputs with waveform generation
  • Onboard 1 k-sample D/A FIFO
  • 24-CH TTL digital input/output
  • 2-CH 16-bit general-purpose timer/counter
  • Analog and digital triggering
  • Fully auto calibration
  • Multiple cards synchronization through SSI (System Synchronization Interface) bus

Specifications

  • Analog Input

    • Resolution: 16 bits, no missing codes
    • Number of channels: 64 single-ended or 32 differential (software selectable per channel)
    • Channel gain queue size: 512
    • Maximum sampling rate: 500 kS/s
    • Programmable gain: 1, 2, 4, 5, 8
    • Bipolar input ranges: ±10 V, ±5 V, ±2.5 V, ±1.25 V
    • Unipolar input ranges: Max. : 0-10 V, 0-5 V, 0-2.5 V, 0-1.25 V
    • Offset error: ±1 mV
    • Gain error: ±0.01% of FSR
    • Input coupling: DC
    • Overvoltage protection: Power on: Continuous ±30 V, Power off: Continuous ±15 V
    • Input impedance: 1 GΩ/100 pF
    • CMRR (gain = 1): 83 dB
    • Settling time: 2 μs to 0.1% error
    • -3 dB small signal bandwidth (gain = 1): 1.6 MHz
    • Trigger sources: Software, external digital/analog trigger, SSI bus
    • Trigger modes: Pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger
    • FIFO buffer size: 1 k samples
    • Data transfers: Polling, scatter-gather DMA

  • Analog Output

    • Number of channels: 2 voltage outputs
    • Resolution: 12 bit
    • Output ranges: 0-10 V, ±10 V, 0-AOEXTREF, ±AOEXTREF
    • Maximum update rate: 1 μs
    • Slew rate: 20 V/μs
    • Settling time: 3 μs to ±0.5 LSB accuracy
    • Offset error: ±1 mV
    • Gain error: ±0.02 % of max. output
    • Driving capacity: ±5 mA
    • Stability: Any passive load, up to 1500 pF
    • Trigger sources: Software, external digital/analog trigger, SSI bus
    • Trigger modes: Post-trigger, delay-trigger, and repeated trigger
    • FIFO buffer size: 1 k samples
    • Data transfers: Programmed I/O, scatter-gather DMA

  • Digital I/O

    • Number of channels: 24-CH 8255 programmable input/output
    • Compatibility: 5 V/TTL
    • Data transfers: Programmed I/O

  • General Purpose Timer/Counter

    • Number of channels: 2
    • Resolution: 16 bit
    • Base clock available: 40 MHz, external clock up to 10 MHz

  • Auto Calibration

    • Onboard reference: +5 V
    • Temperature drift: ±2 ppm/˚C
    • Stability: ±6 ppm/1000 Hrs

  • General Specifications

    • Dimensions: 175 mm x 107 mm (not including connectors)
    • Connector: 68-pin VHDCI female x 2
    • Operating temperature: 0 to 55˚C
    • Storage temperature: -20 to 70˚C
    • Humidity: 5 to 95 %, non-condensing
    • Power requirements: +5 V 1.2 A typical

Software Support

  • Operating Systems

    • Windows 7/Vista/XP/2000/2003 Server
    • Linux

  • Recommended Software

    • AD-Logger
    • VB.NET/VC.NET/VB/VC++/BCB/Delphi
    • DAQBench

  • Driver Support

    • DAQPilot for Windows
    • DAQPilot for LabVIEW
    • DAQ-MTLB for MATLAB
    • D2K-DASK for Windows
    • D2K-DASK/X for Linux

Ordering Information

  • DAQ-2205 - 32/64 x 16-bits 500 kS/s Multi-Function DAQ Card

Accessories

  • Terminal Boards

    • DIN-68S-01 - Terminal Board with One 68-pin SCSI-II Connector and DIN-Rail Mounting (cables are not included)

  • Cables

    • ACL-10568-1 - 68-Pin SCSI-VHDCI cable

  • SSI Bus Cables (for multiple cards synchronization)

    • ACL-SSI-2 - SSI Bus cable for 2 devices

    • ACL-SSI-3 - SSI Bus cable for 3 devices

    • ACL-SSI-4 - SSI Bus cable for 4 devices
