Features
- General Features
- Quickly and Cost Effectively integrate networks
- Provide PWR/Communication Status indication LED
- Read/Write any standard Modbus register via BACnet
- No Programming Required
- Modbus register mapping configured via web interface
- BACnet
- Fully Compliant with BACnet/IP Server
- Supports up to 200 objects each of types: Analog Input, Analog Output, Analog Value, Binary Input, Binary Output, Binary Value, Multi-State Input, Multi-State Output,
- BIBB (BACnet Interoperability Building Blocks) Supported: DS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM-B, DS-COV-B, DM-DDB-B, DM-DOB-B, DM-DCC-B, DM-TS-B, DM-UTC-B, DM-RD-B
- Modbus TCP
- Fully User Configurable Modbus TCP Client
- Supports Modbus coils, input register, holding registers.
- Supports for Function Code 0x01, 0x02, 0x03, 0x04, 0x05, 0x06, 0x10, 0x0F.
- System
- CPU: 32-bit
- SDRAM: 128 MB
- Flash: 64 MB
- EEPROM: 16 KB
- Communication Ports
- COM1: RS-232 (RxD, TxD, and GND); Non-isolation
- Ethernet: 10/100Base-TX Ethernet Controller
- Protocol
- Modbus: Modbus TCP Client
- BACnet: BACnet/IP Server
- BACnet Objects: AI, AO, AV, BI, BO, BV, MSI, MSO, MSV (Maximum: 200 each)
- BIBB Supported: DS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM-B, DS-COV-B, DM-DDB-B, DM-DOB-B, DM-DCC-B, DM-TS-B, DM-UTC-B, DM-RD-B
- Mechanical
- Dimensions (W x L x H): 91 x 132 x 52 mm
- Installation: DIN-Rail
- Environmental
- Operating Temp.: -25 ~ +75°C
- Storage Temp.: -30 ~ +85°C
- Humidity: 5 ~ 90% RH, non-condensing
- Power
- Input Range: +10 ~ +30 Vdc
- Isolation: 1 kV
- Consumption: 4.8 W (0.2 A @ 24 Vdc)
- GW-5493 – BACnet/IP to Modbus TCP Gateway
